Application

Water tank, water treatment,etc,used for detecting liquid level.

Origin

FAST SENSOR

Installation

Only Vertical

Detected Depth

□ L=45~150mm  □150~500mm

Product Material

□ SS=SUS304 & SUS316 Stem &Ball

□ SP= SUS304 & SUS316 Stem &PP Sealed Ball

□ S= SUS304 & SUS316 Stem &PP Foam Ball

Waterproof Ring

□ in water, silica gel material ,clear color

□ in oil, rubber material, black

□ In ink & chemical liquid, EPDM material, black

Electrical Data

□ 1=10W,100V,0.5A   □ 2=70W,250V,0.5A  □100W/400VAC/ 1A

Switching Form

A=Normal Open N/O

Detected Level

□ 1=D1 Shortage alarm   □ 2=D2 Full alarm

Sensing Form

□ V= Reversible Action   □ No V= Irreversible Action

Thread

3/8", 1/8NPT,M10(42-150mm),M12(120-500mm)

Wire Material

□ W=Teflon#22 Blue(Standard)   □ C3.8=φ3.8 Cable Black  □ C4.5=φ4.5 Cable Black

Wire Length

□ 300mm(Standard)   □ 500   □ 1000   □ Other

Connector

□ 2Y=Made in China   □ SM=Made in Korea   □ JST=Made in Janpan   □ Other

Output Signal

ON/OFF, 2 wires

Temperature ℃

□ -40~+85   □ HT -40 ~ +140

Order Info.

For example, FAST-45LSS-2A1V-M10-300W-2Y

FAST-45mm depth,SUS304 stem and ball-70W,N/O, Shortage alarm from the bottom -M10-300mm,#22-Chinese connector
